Software substitute for Nakamichi T-100 Audio Analyzer

[Cobra2]







NAK T-100 software simulator



NAK T-100 is a lightweight and all-inclusive audio analyzer for inspecting analog audio devices on computer. It is capable of performing 7+ conventional audio measurements in a single setup without swapping a stack of physical instruments. This makes it an agile tool to quickly check whether a given audio device performs to its specifications. Or during a service/repair/modify project, this is a less overkill yet more cost-effective tool for conducting general audio measurements on desk top. Some of the key functions are specifically optimized for tuning analog tape players/recorders.



The app features modern DSP core with traditional analog skin. It adopts the "Skeuomorphism" design philosophy to offer era-specific operational experience in working with analog audio devices. However, the underlaying engine works purely from digital domain after all, which does not have to follow the analog measurement principles and yield strict identical readings. Typical tolerances across typologies of test instruments should be expected.





Features and Specifications

[Generator]

  21 spot sinusoidal plus pink noise and square wave

[Level]

  -80dB ~ +10dB

  (extendable to +30dB with physical input attenuator),

  RMS or peak, 0dB = 1.0V (after calibration)

[AC Volt]

  10mV ~ 300mV, 0.1V ~ 1V,

  1V ~ 10V (with physical input attenuator)

  20Hz ~ 20kHz

  Requires calibration with reference AC volt-meter

[THD+N]

  0.01% ~ 0.3%, 0.1% ~ 3%

  400Hz/1000Hz

[Speed]

  3000Hz/3150Hz ±3%

[Wow & Flutter]

  0.01% ~ 0.3%, 0.1% ~ 3%

  Quasi-Peak DIN 45507

  WRMS DIN 45507

  Peak unweighted

  RMS unweighted

  Spectrum display: 0.2 ~ 100Hz

[Signal/Noise Ratio]

  -100dB ~ -10dB

  IHF-A weighted

[Frequency Response]

  20 ~ 20kHz (extendable to 40kHz at 88.2kHz sample rate or higher)

  -100dB ~ +10dB

  Gaussian white noise

  Pink noise

  Sweep frequency (asynchronous)

[Lissajous]

  Ellipse figure with time stabilizer

[Oscilloscope]

  Two channel, non-quantitative

[Meter Ballistics]

  RMS: 300mS

  Peak: 10mS raise, 2000mS fall

[Sound Card]

Must have standard stereo input and output.

Sample rate 44.1kHz ~ 96kHz (higher sample rate may work but without guarantee)



http://www.anaxwaves.com/NAKT100/

[sherlock]

Funkcje:

Signal Generator

Level Meter (RMS/Peak)

Signal/Noise Ratio

Total Harmonic Distortion

Wow and Flutter

Frequency Response

Oscilloscope

Lissayous Pattern



Wymagania systemowe:

Komputer, Urządzenie przenośne, Surface Hub, HoloLens

System operacyjny: Windows 10 wersja 18362.0 lub nowszy

Architektura: x86, x64, Arm

Mysz: Zintegrowana mysz (Minimum)

Procesor: > 2.4GHz, > 2x core

Uwagi: CPU: >2.4GHz with at least two cores;Stereo Audio Input (ideally Line-In);Stereo Audio Output (ideally Line-Out)
