Aurex PC-X60AD

[sherlock]



Aurex PC-X60AD

Specyfikacja:

Type: 2-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.75 cm/s
Heads: 1 x record/playback, 1 x erase
Motor: 1 x capstan, 1 x reel
Tape Type: type I, CrO2, Metal
Noise Reduction: B, ADRES
Frequency Response: 20Hz to 20kHz  (Metal tape)
Signal to Noise Ratio: 58dB (peak level, WTD) without noise reduction

                                   63dB  (peak level, WTD) with Dolby NR

                                  80dB  (peak level, WTD) metal tape with ADRES

Dynamic range: 100 dB   (ADRES in, 1kHz, metal tape)

Wow and Flutter: 0.035%
Total Harmonic Distortion: 0.3%

Bias frequency: 85 kHz
Input: 70mV (line), 0.25mV (mic)
Output: 0.4V (line)
Semiconductors: 10 x IC, 75 x transistors, 51 x diodes, 3 x LED
Dimensions: 420 x 120 x 280mm
Weight: 6kg
Year: 1979-1980







Zawsze mi się podobał to go mam

[sherlock]



[sherlock]

Na pokładzie mamy system ADRES, o którego działaniu informuje stosownie podświetlony napis.
